分类：画屏系列；型号：LZHY65T601
|
规格 |
参数 |
|
|
液晶屏/LCD Panel |
屏幕尺寸/Screen Size (Diag.) |
65” |
|
背光类型/Backlight Type |
DLED |
|
|
分辨率/Resolution |
3840*2160 |
|
|
显示尺寸(mm) |
1428.48(H)× 803.52(V) |
|
|
像素点距(mm) |
0.372(H) x 0.372(V) |
|
|
响应时间/Response Time |
8ms(typ.) |
|
|
面板亮度/Brightness |
350cd/m2 (Center 1point ,Typ.) |
|
|
对比度/Contrast Ratio |
1200:1 |
|
|
可视角度/Viewing Angle(CR>10) |
178° |
|
|
色彩深度 |
1.07B |
|
|
色域/Colour Gamut(NTSC) |
72% |
|
|
宽高比/Aspect Ratio |
16:9 |
|
|
刷新频率 |
60Hz |
|
|
硬件配置/Hardware configuration |
芯片组/Chipset |
MSD6A8386 |
|
系统版本/OS |
Android 8.0 |
|
|
CPU/GPU |
A73*2+A53*2/G51 MP2 |
|
|
DDR/eMMC |
3G/32G |
|
|
WiFi |
2.4GHz&5GHz |
|
|
选配 |
OPS：I3/ I5/ I7(可选) |
|
|
声音/Sound |
内置扬声器/Built-in Speakers |
10W*2 |
|
触控/Touch |
触控规格 |
红外触控框 |
|
玻璃规格 |
3mm 钢化玻璃 |
|
|
响应速度 |
＜10ms |
|
|
触控精度 |
90%以上的区域为±1mm |
|
|
输出形式 |
HID标准 |
|
|
理论点击次数 |
无限次 |
|
|
最小触摸物体直径 |
≥2mm |
|
|
输入输出接口/ |
RJ45 |
1 |
|
HDMI IN |
2 |
|
|
USB 2.0 |
4 |
|
|
VGA |
1 |
|
|
RS232 |
1 |
|
|
Mini AV IN |
1 |
|
|
AV OUT |
1 |
|
|
Earphone/line out |
1 |
|
|
Touch USB |
1 |
|
|
PC Audio |
1 |
|
|
SPDIF OUT |
1 |
|
|
SD Card |
1 |
|
|
电源/power |
输入电源/Input Power |
100V-240VAC 50/60Hz |
|
最大功耗/Power Consumption |
≤250W |
|
|
待机功耗/Power Consumption (Standby) |
≤0.5W |
|
|
环境条件/Environmental Conditions |
工作温度/Operating Temp. |
0-40℃ |
|
工作湿度/Operating Humid |
20%-80% |
|
|
产品规格/ Physical Spec |
整机尺寸/Dimension (LxWxH) |
1486.2*90.7*889.7mm |
|
包装尺寸/Package Dimension (LxWxH) |
1695*223*1053mm |
|
|
净重/Net Weight |
37±2Kg |
|
|
毛重/Gross Weight |
50±2Kg |
|
|
壁挂孔位/Wall hanging size(mm) |
400.0(H) x 400.0（V） |
|
|
壁挂螺钉直径(mm) |
M8 x L25 |
|
